    Product Details
  • Name:Power Relay
  • Model:NB903-12S-S-A 30A 12V
  • Brand:SINETONG
  • Summary:Rated current:30A;Size:32*27.2*20mm
Detailed Product Description



ORDER INFORMATION



NB903     _     –AC220     S     --S      --A      4      -L
       1       2              3        4       5         6       7      8

1.Model Number: NB903

2.E: Max 30A for NO Type     Without E: Max 40A for NO Type

3.Coil Rated Voltage: 24V; 110V; 120V; 220V; 240V; 270V(AC)

4. Construction: S:Sealant ;      D: Dust-proof

5.Contact Material: S:AgSnO2     C: AgCdO

6.Contact Form: A:Normal Open(NO)      B:Normal Close(NC)      C:Conversion(C)

7.Pin-out Form :
A4: without middle pin-out for NO type          A5: with middle pin-out for NO type
B4: without middle pin-out for NC type          B5: with middle pin-out for NC type
C5: without middle pin-out for conversion     C6: with middle pin-out for conversion

8. Low profile (H: 20mm)
